| Capacity | : | 18 GPD |
| Control Type | : | Automatic |
| Coverage Area | : | 5,300 sq ft |
| Depth | : | 15.91 in |
| Drain Connection Size | : | 1/2 in |
| Drain Connection Type | : | Barb |
| Height | : | 18 in |
| Inlet Connection Size | : | 1/4 in |
| Inlet Connection Type | : | Compression |
| Installation / Mounting Type | : | Duct Mount |
| Operating Temperature Rating | : | 60-120 F |
| Package Quantity | : | 1 |
| Phase | : | 1 ph |
| Plenum Opening Size | : | 14.75 x 14.31 in |
| Product Family | : | 700 Series |
| Product Type | : | Evaporative Humidifier |
| Product Weight | : | 17 lbs |
| Shipping Weight | : | 17 lbs |
| Voltage Rating | : | 24 V |
| Width | : | 11.35 in |
The Aprilaire® 700 is a high-capacity, fan-powered whole-house humidifier designed to provide balanced humidity for large, tightly constructed homes. It delivers up to 18 gallons of moisture per day to improve indoor air quality, relieve symptoms of dry air, and protect wood furnishings from cracking and warping.This duct-mounted unit integrates directly with the home's HVAC system, using its built-in fan to pull warm air from the supply plenum for efficient, natural evaporation. The included Model 60 Automatic Digital Humidistat provides precise, set-it-and-forget-it control by using an outdoor temperature sensor to automatically maintain the ideal humidity level.
- High-Capacity Humidification: Delivers up to 18 gallons of moisture per day to effectively humidify tightly constructed homes as large as 5,300 square feet.
- Automatic Digital Control: Includes the Model 60 humidistat, which features a backlit LCD and automatically adjusts humidity levels based on outdoor temperature readings.
- Fan-Powered Efficiency: An internal fan pulls heated air directly from the furnace plenum, ensuring efficient water evaporation, making it an ideal choice for systems with low or variable-speed air handlers.
- Complete Installation Kit: Comes with all necessary components, including the humidifier, Model 60 humidistat, Model 35 Water Panel® , outdoor temperature sensor, 24VAC transformer, and saddle valve.
- Blower Activation Mode: The controller features a Blower Activation mode that allows the humidifier to run with the HVAC system's fan, even without a call for heat.
