| Capacity | : | 34.6 GPD |
| Control Type | : | Automatic |
| Coverage Area | : | 6,000 sq ft |
| Depth | : | 10.13 in |
| Drain Connection Size | : | 7/8 in |
| Drain Connection Type | : | Barb |
| Height | : | 20.88 in |
| Inlet Connection Size | : | 1/4 in |
| Inlet Connection Type | : | Compression |
| Installation / Mounting Type | : | Duct Mount~Wall Mount |
| Maximum Overcurrent Protection (MOCP) | : | 20~25 A |
| Operating Temperature Rating | : | 32-140 F |
| Package Quantity | : | 1 |
| Phase | : | 1 ph |
| Product Family | : | 800 Series |
| Product Type | : | Steam Humidifier |
| Product Weight | : | 23 lbs |
| Shipping Weight | : | 28 lbs |
| Voltage Rating | : | 120~208/240 V |
| Watts | : | 1.4-3.8 kW |
| Width | : | 7.13 in |
The Aprilaire® 800 Series Steam Humidifier is a high-capacity solution for maintaining optimal humidity in large homes up to 6,000 sq ft. It is ideal for applications where evaporative humidifiers are impractical, such as in homes with crawl spaces, attics, or certain non-forced air heating systems.Using electrode technology to boil water and create pure steam, this unit delivers consistent humidity through your HVAC system. It includes a fully automatic digital control, allowing for precise, set-and-forget operation to ensure whole-home comfort.
- Automatic Control: Includes a Model 62 Automatic Digital Humidifier Control with an outdoor sensor to automatically adjust humidity levels and activate the blower when needed.
- Efficient Steam Dispersion: A specially designed dispersion tube delivers hot, dry steam into the ductwork, ensuring effective absorption and preventing condensation.
- Intelligent Management: An internal control board manages performance, monitors canister life with a service indicator light, and automatically drains the unit after 72 hours of inactivity.
- System Protection: Drain water tempering uses cold inlet water to protect PVC piping, while a water level sensor and backflow protection prevent overfilling and pressure buildup.
- Complete Package: Comes with everything needed for a standard installation, including a steam canister, steam hose, drain tubing, dispersion tube, and saddle valve.
- Versatile Installation: Can be mounted directly to the ductwork for a variety of forced-air heating system applications.
