JB Industries A32600 Coupler, 45 deg Coupler Fitting, Connection Size 1: 1/4 in, 45 deg Angle, Brass, 3 in Length
JB Industries A32600 Coupler, 45 deg Coupler Fitting, Connection Size 1: 1/4 in, 45 deg Angle, Brass, 3 in Length

JB Industries A32600 Coupler, 45 deg Coupler Fitting, Connection Size 1: 1/4 in, 45 deg Angle, Brass, 3 in Length

JB Industries A32600 Coupler, 45 deg Coupler Fitting, Connection Size 1: 1/4 in, 45 deg Angle, Brass, 3 in Length

Manufacturer: JB Industries
Brand: JB Industries
Part #: 306567
MPN: A32600
CPN:
Angle      :      45 deg
Connection Size 1      :      1/4 in
Connection Type 1      :      45 deg SAE Female Flare Swivel Tube
Depth      :      7 in
Fitting Type      :      45 deg Coupler
Length      :      3 in
Material      :      Brass
Package Quantity      :      10 Pack
Product Weight      :      0.39 lb
Width      :      1-1/2 in

JB Industries Coupler, 45 deg Coupler Fitting, Connection Size 1: 1/4 in, 45 deg Angle, Brass, Connection Type 1: 45 deg SAE Female Flare Swivel Tube, 3 in Length, 1-1/2 in Width, 7 in Depth

  • American Made Brass
  • For use with copper, brass, aluminum, steel, and plastic tube provided an acceptable flare could be generated with the material
  • Vacuum and pressures of 5,000 psi can be handled depending upon the size, material, and conditions. The valve core is typically the limiting restriction at 800 psi max. working pressure
  • Long nuts are recommended when vibration is a factor. Tubing should be double-flared in extreme applications to minimize flare thinning on over-tightening
  • Fittings listed generally comply with SAE, ASA, ASME, and MS standards; however, when design makes dimensions critical, please contact customer service for samples and/or prints for testing and evaluation
  • Pipe sizes listed are standard nominal pipe size and threads are to dry seal taper pipe standards
  • JB provides flare fitting to SAE Standard J513 whenever possible. Slight deviations can occur when full compliance fittings are not available
  • Most heavy-duty ACR tube fittings conform to SAE, ASA, and AHRI Standards for hydraulic, marine, and refrigeration service
  • Long dry seal pipe threads minimize leakage and provide more clearance for tightening flare nuts
  • Shapes, elbows, tees, etc., are made from brass forgings to maximize strength and eliminate cracks
  • Our access fittings have generous counter bores to allow for the removal of the core if the flare becomes damaged
  • Many tees and crosses are tapped to receive and access core in all 1/4" SAE flare ends
  • Most valves are equipped with cap and one valve core (braze type, loosely assembled)
  • Temperature range -20 degrees to +220 degrees Fahrenheit (-40 to 121.1 degrees Celsius)
  • Valve core utilizes materials that can be used with most refrigerants including R410A
