| Amperage Rating | : | 1.5 A |
| Compatible Models | : | RADD~RAJB~RAKA~RAMA~RAMB~RAPA~RAPB~RKKA~RPDC~RPKA~RPLA~RPMB~RPMC~RPML~RRKA-A~RRMA-A |
| Depth | : | 5.625 in |
| For Use With | : | Condenser |
| Function Type | : | Condenser Fan Motor |
| Height | : | 4.5 in |
| Motor HP | : | 1/3 HP |
| Motor RPM | : | 1,075 RPM |
| Motor Type | : | PSC |
| NEMA Frame Size | : | 48 |
| Number of Speeds | : | 1 |
| Package Quantity | : | 1 |
| Packaged Depth | : | 14.7 in |
| Packaged Height | : | 6.85 in |
| Packaged Width | : | 7.1 in |
| Phase | : | 1 ph |
| Product Family | : | ProTech |
| Rotation Direction | : | CCW |
| Shaft Diameter | : | 0.5 in |
| Shaft Length | : | 2.063 in |
| Shipping Weight | : | 11.59 lbs |
| Voltage Rating | : | 208/230 V |
| Width | : | 5.625 in |
This ProTech condenser fan motor is a genuine OEM replacement part for air conditioning units. It is designed to efficiently transfer heat from the refrigerant system to the outdoor air, which is critical for preventing the AC compressor from overheating and extending the life of the equipment. As a factory-authorized ProTech part, this motor is built to match the original component's specifications, ensuring a straightforward installation and consistent, reliable performance.
