Rheem® 51-23053-11 ProTech 1/3 HP 1-Speed PSC Condenser Fan Motor - 1,075 RPM, 208/230V, 1 ph, Reversible
Rheem® 51-23053-11 ProTech 1/3 HP 1-Speed PSC Condenser Fan Motor - 1,075 RPM, 208/230V, 1 ph, Reversible
Manufacturer: Rheem® Manufacturing
Brand: Rheem®
Part #: 304882
MPN: 51-23053-11
CPN:
| Amperage Rating | : | 1.75 A |
| Depth | : | 4 in |
| For Use With | : | Condenser |
| Function Type | : | Condenser Fan Motor |
| Height | : | 7 in |
| Motor HP | : | 1/3 HP |
| Motor RPM | : | 1,075 RPM |
| Motor Type | : | PSC |
| NEMA Frame Size | : | 48 |
| Number of Speeds | : | 1 |
| Package Quantity | : | 1 |
| Phase | : | 1 ph |
| Product Family | : | ProTech |
| Product Type | : | MOTORS |
| Product Weight | : | 11.68 lbs |
| Rotation Direction | : | Reversible |
| Shaft Diameter | : | 0.5 in |
| Shaft Length | : | 4.25 in |
| Voltage Rating | : | 208/230 V |
| Width | : | 7.15 in |
The ProTech 51-23053-11 is a 1/3 HP condenser fan motor designed for reliable performance in residential and light commercial HVAC systems. This single-speed motor operates at 1,075 RPM and is compatible with 208/230V single-phase power supplies.Engineered as a replacement part for various Rheem® and WeatherKing units, it can also be adapted for other retrofit applications. Its robust design ensures consistent cooling performance and long-term durability.
