| AFUE | : | 80 % |
| Air Flow Direction | : | Upflow~Horizontal~Multi-Position |
| BTU Heating Input Rating (Custom) | : | 96,000 BTU/h |
| BTU Heating Input | : | 100,000 BTU/h |
| BTU Heating Output Rating (Custom) | : | 84,000 BTU/h |
| BTU Heating Output | : | 80,000 BTU/h |
| CFM Airflow (Custom) | : | 1,650 CFM |
| CFM Airflow | : | 1,600 CFM |
| Communicating | : | Yes |
| Depth | : | 29.59 in |
| Energy Star Certified | : | No |
| Fuel Type | : | Natural Gas~Liquid Propane |
| Height | : | 34 in |
| Ignition Type | : | Direct Spark |
| MBH | : | 100 MBH |
| Model Number | : | R802V |
| Motor Type | : | Constant CFM / Variable Speed |
| Number of Stages | : | Two-Stage |
| Phase | : | 1 ph |
| Product Family | : | Endeavor Line Classic Plus |
| Product Weight | : | 131.5 lbs |
| Vent Type | : | Type B |
| Voltage Rating | : | 115 V |
| Width | : | 17.5 in |
The Rheem® Endeavor Line Classic Plus R802V is an 80% AFUE gas furnace designed for reliable performance and enhanced home comfort. Its two-stage heating and constant CFM variable-speed motor work together to provide consistent temperatures and superior humidity control while maintaining quiet operation.Built for versatility and ease of use, this furnace features a multi-position design for upflow or horizontal installation. It is also EcoNet® enabled, allowing for advanced communicating control and system monitoring when connected to compatible equipment.
- Smart Diagnostics: Use the Rheem® Contractor and EcoNet® Apps with built-in Bluetooth® technology for easy monitoring, troubleshooting, and repairs.
- Simplified Commissioning: Features dip-switch-free setup via Bluetooth and the contractor app for a faster, more seamless installation.
- Variable Speed Motor: The Constant CFM motor provides true variable speed operation for enhanced humidity control, quieter performance, and year-round energy savings.
- Two-Stage Operation: Operates primarily at a lower, energy-saving capacity of around 60-65% and switches to high capacity as needed for stable heat distribution.
- Reliable Ignition: Equipped with the PlusOne® Direct Spark Ignition (DSI) system for proven reliability and a long service life.
- Quiet Performance: A fully insulated blower cabinet and solid bottom design contribute to exceptionally quiet operation.
