| Air Flow Direction | : | Upflow~Downflow~Horizontal~Multi-Position |
| BTU Rating (Custom) | : | 60,000 BTU/h |
| BTU Rating | : | 60,000 BTU/h |
| Coil Casing | : | Cased |
| Coil Material | : | Aluminum Fin~Aluminum Tube |
| Depth | : | 21.688 in |
| Drain Pan Material | : | Composite / Polymer |
| Height | : | 35 in |
| Liquid Line Size | : | 3/8 in |
| Model Number | : | RCFY |
| Product Family | : | Endeavor |
| Product Weight | : | 76 lbs |
| Refrigerant Type | : | R-454B |
| Refrigeration Control Type | : | EEV |
| Shipping Weight | : | 86 lbs |
| Suction Line Size | : | 7/8 in |
| Tonnage | : | 5.0 Ton |
| Width | : | 21 in |
The Rheem Endeavor 5-ton cased coil is engineered for multi-position applications, including upflow, downflow, and horizontal configurations, making it a versatile choice for installations with gas and oil furnaces. Designed to be paired with a variety of Rheem outdoor units, this coil provides 60,000 BTU/h of nominal cooling capacity.Constructed with aluminum fins and internally grooved aluminum tubing, this unit is factory leak-tested to ensure reliability. It features a unique drain pan design for efficient condensate removal and is compatible with the low-GWP R-454B refrigerant, aligning with modern environmental standards.
- Refrigerant Detection:Features the Plus
- One® Refrigerant Detection System™, which integrates an A2
- L sensor and mitigation board to protect the system by pausing operation if excess refrigerant is detected.
- Durable Construction:Built with aluminum fins bonded to internally grooved aluminum tubing for reliable performance and heat transfer.
- Flexible Installation:A bi-directional airflow design allows for easy installation in horizontal left or right configurations without reconfiguring internal components.
- Enhanced Drainage:Equipped with a corrosion-free, thermal-set drain pan that has a unique design and dual 3/4 in NPT connections to maximize condensate removal.
- Compact Design:The N-Coil design maximizes system performance while minimizing the coil's height, simplifying installations in tight spaces.
- Future-Ready Refrigerant:Designed for use with R-454
- B, a low Global Warming Potential (GWP) refrigerant that meets 2025 EPA requirements.
