| Air Flow Direction | : | Upflow~Downflow~Horizontal~Multi-Position |
| BTU Rating | : | 24,000 BTU/h |
| Coil Casing | : | Cased |
| Coil Material | : | Aluminum Fin~Aluminum Tube |
| Depth | : | 21.6 in |
| Drain Pan Material | : | Composite / Polymer |
| Height | : | 20 in |
| Liquid Line Size | : | 3/8 in |
| Model Number | : | RCFZ |
| Number of Rows | : | 2 |
| Product Family | : | Endeavor |
| Product Weight | : | 49 lbs |
| Refrigerant Type | : | R-410A |
| Refrigeration Control Type | : | TXV |
| Shipping Weight | : | 54 lbs |
| Suction Line Size | : | 3/4 in |
| Tonnage | : | 2.0 Ton |
| Width | : | 17.5 in |
This Rheem® Endeavor line cased coil is designed for use with Rheem® outdoor units and gas or oil furnaces, providing a versatile solution for various system configurations. Its multi-position design allows for vertical upflow, downflow, or horizontal installation, offering flexibility for both new construction and retrofit projects.Constructed with aluminum fins bonded to internally grooved aluminum tubing, this coil ensures efficient heat transfer. It features copper sweat refrigerant connections and comes equipped with a TXV for precise refrigerant control, contributing to reliable system performance.
- N-Coil Design: Maximizes performance and minimizes the height required for installation, making it suitable for tight spaces.
- Installation Flexibility: Features bi-directional airflow, which eliminates the need to switch internal components for horizontal applications.
- Durable Drain Pan: Constructed from a high-grade, heat-resistant, and corrosion-free thermal-set material for long service life.
- Convenient Drainage: Equipped with two sets of 3/4 in N.P.T. condensate drain connections to simplify installation and ensure effective water removal.
- Factory Tested: Undergoes an extensive refrigerant leak check at the factory to ensure reliability upon arrival.
- UV Resistant: Materials are compatible with germicidal light systems, allowing for enhanced indoor air quality options.
