| Air Flow Direction | : | Upflow~Downflow~Horizontal~Multi-Position |
| BTU Rating | : | 48,000 BTU/h |
| Coil Casing | : | Cased |
| Coil Material | : | Copper |
| Depth | : | 20.5 in |
| Drain Pan Material | : | Composite / Polymer |
| Height | : | 25.5 in |
| Model Number | : | HE |
| Product Family | : | HE Series |
| Product Weight | : | 64 lbs |
| Refrigerant Type | : | R-454B |
| Refrigeration Control Type | : | TXV |
| Suction Line Size | : | 7/8 in |
| Tonnage | : | 4.0 Ton |
| Width | : | 24.5 in |
The Advanced Distributor Products (ADP) HE Series is a premier cased evaporator coil designed for high-efficiency performance with modern HVAC systems. This 4.0 Ton unit offers versatile multi-position installation capabilities, including upflow, downflow, and horizontal configurations, to fit a wide range of applications.Engineered for compatibility with low-GWP A2L refrigerants like R-454B, the coil features a high-efficiency lanced fin design and a fully insulated cabinet to maximize thermal performance and ensure system reliability.
- Advanced Drain Pan: Features a patented HydroTEC™ low water retention drain pan made from UV-resistant polymer with a Microban® antimicrobial additive to inhibit mold and mildew growth.
- Durable Construction: Built with copper tubing and corrosion-resistant coil header plates to ensure long-lasting performance and reliability.
- High-Performance Cabinet: The cased cabinet is fully lined with 5/8" foil-faced insulation and is Intertek lab tested to have 1% or less air leakage for improved efficiency.
- Service-Friendly Design: Designed for easy installation with a short cabinet height, non-captive refrigerant lines, and interlocking doors for simple access.
- A2L Refrigerant Compatible: Engineered for use with modern, low-GWP A2L refrigerants including R-454B and R-32 for both AC and heat pump applications.
