| BTU Cooling Rating (Custom) | : | 18,000 BTU/h |
| BTU Cooling Rating | : | 18,000 BTU/h |
| BTU Heating Rating (Custom) | : | 18,000 BTU/h |
| BTU Heating Rating | : | 18,000 BTU/h |
| Compressor Type | : | Rotary |
| Depth | : | 13.46 in |
| EER (Custom) | : | 12.0 |
| EER2 Range | : | 11.7-12.5 |
| EER2 | : | 11.0~12.0 |
| EER | : | 12.5 |
| ENERGY STAR Certified | : | Yes |
| HSPF (Custom) | : | 10.0~11.0~12.0~13.0 |
| HSPF2 Range | : | 9.5-11.3 |
| HSPF2 | : | 9.0~10.0~11.0 |
| HSPF | : | 10.3-13.0 |
| Height | : | 26.5 in |
| Liquid Line Size | : | 1/4 in |
| Max Breaker Size | : | 25 A |
| Model Number | : | BMS500 |
| Number of Stages | : | Variable-Stage |
| Number of Zones | : | 1 |
| Phase | : | 1 ph |
| Product Family | : | Climate 5000 |
| Product Type | : | Heat Pump |
| Product Weight | : | 100.97 lbs |
| Refrigerant Type | : | R-410A |
| SEER (Custom) | : | 19.0~20.0~21.0 |
| SEER2 Range | : | 18.0-21.5 |
| SEER2 | : | 18.0~19.0~20.0~21.0 |
| SEER | : | 19.6-21.5 |
| Suction Line Size | : | 1/2 in |
| Tonnage | : | 1.5 Ton |
| Voltage Rating | : | 208/230 V |
| Width | : | 35.04 in |
The Bosch Climate 5000 is a single-zone ductless mini-split outdoor heat pump designed to provide efficient and reliable comfort for residential applications, especially where ductwork is not an option. This ENERGY STAR certified unit delivers variable-stage performance for precise temperature control and energy savings.Engineered for superior performance in extreme weather, this system maintains consistent heating capacity in freezing temperatures and provides cooling operation in sub-zero conditions, ensuring year-round comfort.
- Low-Temperature Heating: Delivers 100% heating capacity in ambient temperatures between -5°F and 5°F, depending on system configuration.
- Extreme Cooling: Provides reliable low-ambient cooling operation in temperatures down to -22°F without requiring an additional accessory kit.
- Base Pan Heater: Includes a factory-installed base pan heater to prevent ice accumulation and ensure proper drainage in cold climates.
- Thermostat Flexibility: Compatible with the Bosch Connected Control (BCC) Wi-Fi thermostat family and includes a 24V interface for use with standard thermostats.
- Quiet Operation: Engineered for whisper-quiet performance, with outdoor unit sound levels as low as 53 dBA.
- Warranty Protection: Covered by a 10-year compressor and 10-year parts residential warranty.
